Build Your First AI Agent from Scratch - Part 4: Tooling and API Integrations

Our agent now remembers context, but it still only talks. In the Lumenly pilot, that meant a human had to execute every suggestion manually: "Run this SQL," "Send this Slack message," etc. Part 4 closes the loop by connecting the agent to external systems safely.

Thesis: structured tool definitions + guarded execution paths turn language into action. If you rely on free-form instructions ("call the billing API somehow"), you invite bugs and compliance nightmares. We'll design a tool registry, planner middleware, and execution harness that we can trust in production.

---

Architectural Overview

We'll introduce three components:

1. Tool Registry: JSON/YAML definitions describing function signatures, auth, and cost.
2. Planner Middleware: intercepts LLM responses, extracts tool intents, validates against the registry.
3. Executor: performs the API call or local action, logs metrics, and feeds the result back into the conversation.

Sequence diagram:

User -> Agent -> LLM Planner -> Tool Registry -> Executor -> External API
   ^            |            |            |
   \_------------+-- memory --+------------\_

Takeaway: Never let the model call APIs directly--always route through structured registries.

---

Define Tool Schemas

Create tools/registry.yaml:

- name: search_docs
  description: "Search the internal documentation index"
  request:
    method: GET
    url: "https://docs.lumenly.ai/search"
    query:
      q: string
  response:
    format: json
  auth: bearer
  cost_estimate:
    tokens: 0
    latency_ms: 400
- name: create_support_ticket
  description: "Create a Zendesk ticket for follow-up"
  request:
    method: POST
    url: "https://api.zendesk.com/v2/tickets"
    body:
      subject: string
      description: string
      priority: ["low", "normal", "high"]
  auth: oauth
  cost_estimate:
    tokens: 0
    latency_ms: 1200

Parse it:

# src/agent_lab/tools/registry.py
import yaml
from dataclasses import dataclass
from pathlib import Path

@dataclass
class Tool:
    name: str
    description: str
    spec: dict

class ToolRegistry:
    def __init__(self, path: Path):
        raw = yaml.safe_load(path.read_text())
        self.tools = {item["name"]: Tool(item["name"], item["description"], item)}

    def list(self):
        return list(self.tools.values())

    def get(self, name: str) -> Tool:
        return self.tools[name]

Takeaway: Schemas live outside code so ops can review them like any other API contract.

---

Teach the Planner About Tools

Modify LLMClient.complete to include tool metadata. Many providers (OpenAI, Anthropic) support function-calling natively. Example using OpenAI tool specs:

def complete(self, messages: list[Message], tools: list[Tool]) -> dict:
    tool_defs = [
        {
            "type": "function",
            "function": {
                "name": tool.name,
                "description": tool.description,
                "parameters": tool.spec["request"]["body"] or {},
            },
        }
        for tool in tools
    ]
    return self._client.responses.create(
        model=self._model,
        input=[m.__dict__ for m in messages],
        tools=tool_defs,
    )

The response may include tool_calls. Parse them:

result = self.llm.complete(history, registry.list())
tool_calls = getattr(result.output[0].content[0], "tool_calls", [])

Takeaway: Let the model propose actions, but only execute them after validation.

---

Validate and Execute Tool Calls

Create executor.py:

import httpx, json
from agent_lab.tools.registry import Tool, ToolRegistry
from agent_lab.telemetry import emit_metric, logger

class ToolExecutor:
    def __init__(self, registry: ToolRegistry):
        self.registry = registry

    def execute(self, call: dict) -> str:
        tool = self.registry.get(call["name"])
        args = json.loads(call["arguments"])
        self._validate(tool, args)
        response = self._dispatch(tool, args)
        emit_metric("tool.call", name=tool.name, status=response.status_code)
        return response.text

    def _validate(self, tool: Tool, args: dict):
        required = tool.spec["request"].get("body", {})
        for field in required:
            if field not in args:
                raise ValueError(f"Missing {field} for {tool.name}")

    def _dispatch(self, tool: Tool, args: dict):
        request = tool.spec["request"]
        method = request["method"].lower()
        url = request["url"]
        auth_header = {"Authorization": f"Bearer {self._token(tool)}"}
        return httpx.request(method, url, timeout=10, headers=auth_header, json=args)

Wrap in try/except and surface failures back to the agent as system messages ("Tool call failed: ..."). Later we can add retries or circuit breakers per tool.

Takeaway: Executors enforce policy: rate limiting, auth scopes, logging.

---

Close the Loop in CoreAgent

Update send:

result = self.llm.complete(history, self.registry.list())
tool_calls = getattr(result.output[0].content[0], "tool_calls", [])
if tool_calls:
    for call in tool_calls:
        logger.info("tool requested", extra={"tool": call.name})
        try:
            outcome = self.executor.execute(call.to_dict())
            self.store.append(Message("system", f"Tool {call.name} result: {outcome}"))
        except Exception as exc:
            self.store.append(Message("system", f"Tool {call.name} failed: {exc}"))
else:
    reply = Message("assistant", result.output_text)
    self.store.append(reply)
    return reply

This recursion (tool result -> new system message -> next LLM call) lets the agent chain actions.

Takeaway: Treat tool responses as first-class context; the LLM should reason about outcomes explicitly.

---

Example: Weather Lookup Tool

Add a simple tool to illustrate:

- name: weather_lookup
  description: "Get current weather for a city"
  request:
    method: GET
    url: "https://api.weatherapi.com/v1/current.json"
    query:
      key: env:WEATHER_API_KEY
      q: string
  response:
    format: json
  auth: none

Implement _dispatch to substitute env:... tokens automatically. This pattern keeps secrets out of prompt text.

CLI demo:

You: Should I bring an umbrella to Seattle tonight?
Agent: Checking the latest weather data for Seattle...
Agent: Forecast retrieved: light rain, 45degF. Carrying an umbrella is recommended.

Takeaway: Use real APIs sparingly during development; add mock servers or VCR-style fixtures for tests.

---

Testing Strategy

1. Schema validation: run python scripts/validate_tools.py to ensure every registry entry has required fields.
2. Mocked executor tests: use pytest + respx to simulate HTTP calls.

@respx.mock
def test_tool_execution_success(tmp_path):
    respx.get("https://docs.lumenly.ai/search").mock(return_value=httpx.Response(200, json={"hits": []}))
    registry = ToolRegistry(tmp_path / "registry.yaml")
    executor = ToolExecutor(registry)
    call = {"name": "search_docs", "arguments": json.dumps({"q": "billing"})}
    out = executor.execute(call)
    assert "hits" in out

3. End-to-end dry runs: set TOOL_MODE=mock in .env to bypass real APIs and return canned responses. Your CLI should expose a flag (--mock-tools) for testers.

Takeaway: Tooling without tests is a production outage waiting to happen.

---

Operational Safeguards

• Rate Limiting: track tool call frequency, throttle within executor.
• Audit Logs: log tool_name, arguments_hash, status, latency_ms.
• Permissions: map tools to roles; some workflows may restrict which agent persona can call which tool.
• Rollbacks: for mutating actions (e.g., create_support_ticket), emit reversible events (store response IDs so Part 5 can roll them back).

Document these in docs/tooling.md. SRE and security teams should review the registry in the same way they review Terraform changes.

---

What You Can Do Now

Your agent can:

• Inspect the tool catalog.
• Ask the model to select tools.
• Validate and execute API calls.
• Feed tool responses back into context.
• Log every action for audits.

Run a quick test:

python -m agent_lab.cli chat --mock-tools
python -m agent_lab.cli tools list
python -m agent_lab.cli tools describe weather_lookup

If everything looks good, move to Part 5: Testing, Debugging, and Deployment. We'll wire simulations, CI pipelines, and deployment playbooks so these tools run safely in staging and prod.

---
